Gicar Flow Meter Data Sheet Essentials: Pulse Counts and Volumetric Dosing Specs
Quick Answer: The pulse count on a Gicar flow meter data sheet tells you how many electrical pulses the meter sends per liter of liquid. Volumetric dosing specs define the flow range, dose volume, repeatability, and wiring limits you need for a controlled fill. Before you wire the meter to a PLC or batch controller, compare the pulse per liter, K-factor, output frequency, pressure rating, temperature rating, and wetted materials.
Decoding the Pulse Count Field
The pulse count field on a Gicar flow meter data sheet describes how many electrical pulses the meter generates per unit of liquid. Some models state this value as pulses per liter. Others list it as a K-factor in pulses per liter. In practice these two terms mean the same thing for a flow meter with a paddle wheel or Hall sensor. A meter with 450 pulses per liter sends 450 pulses when one liter of water passes through the body. A PLC, batch controller, or dosing board counts those pulses over a set time. From that count the control system calculates flow rate and total volume.
Pulse per Liter and K-Factor Are the Core Numbers
Pulse per liter and K-factor are not decorative numbers. They set the resolution of your dosing loop. A higher pulse per liter value gives more pulses for the same volume. That can improve resolution at small dose sizes. But a very high pulse per liter can overload a slow digital input. Most engineers skip this part and then wonder why a PLC misses counts. Check the maximum output frequency on the data sheet. For example, a meter with 2500 pulses per liter running at 2.0 liters per minute produces about 83 Hz. A basic digital input may read that without issue. At 5000 pulses per liter and 2.0 liters per minute the frequency is about 167 Hz. Some older PLC cards and low speed counters can miss those edges.
Here is the thing. Pulse per liter and K-factor are useful only when the meter has stable repeatability. A cheap meter can list 450 pulses per liter but vary by 3 percent from shot to shot. That error shows up as inconsistent dosing volume. Frequency in Hz equals pulse per liter multiplied by flow rate in liters per minute divided by 60. Use this formula before you select an input card or a batch controller.
Volumetric Dosing Specs That Matter
Volumetric dosing specs go beyond pulse per liter. Look for the minimum dose volume, the flow range, the repeatability, and the response time. A compact meter in this class often has a flow range of 0.15 to 2.5 liters per minute. If you try to dose 30 mL at a target flow of 0.1 liters per minute, you may be outside the linear range. The meter may still output pulses but accuracy drops. Check the data sheet for the minimum flow rate and the maximum flow rate. Stay inside those limits if you want the stated accuracy. Also check the wetted materials. A meter body made of PA or PPS may be fine for water and food. It may crack with strong solvents. Pressure rating and temperature rating are equally important. A typical spec might be 10 bar at 25 degrees Celsius and 6 bar at 90 degrees Celsius. We have seen installations where the temperature rating was ignored. The meter body deformed and the rotor touched the wall.
Output Type and Wiring Notes
Do not ignore the output type. A Gicar flow meter data sheet may say NPN, PNP, open collector, or reed switch. Each output type needs a pull-up resistor or a specific input card. A Hall sensor with NPN output often switches to ground. A PLC input wired for PNP will not read it correctly. The supply voltage matters too. Many compact meters accept 5 to 24 VDC. If you connect 24 VDC to a 5 VDC signal input you can burn the input. Check the cable length and connector. A loose JST plug or a cable routed next to a pump cable can cause false counts. We see this often on coffee machine service calls. The meter itself is fine. The wiring picks up noise from a solenoid or pump. Add a shielded cable or reroute the wire before replacing the m
_600x400.jpg)
A Real Example from a Dosing Skid in Vietnam
Last year a customer in Ho Chi Minh City contacted us about a dosing skid for liquid detergent. The original Gicar flow meter data sheet listed 400 pulses per liter. The customer assumed the meter was too coarse because the PLC was not recording consistent 50 mL doses. We checked the data sheet again. The meter repeatability was plus or minus 1 percent, but the customer was dosing at 0.12 liters per minute. The minimum linear flow rate was 0.20 liters per minute. The meter was not the main issue. The process was below the rated range. We recommended a smaller DN4 meter with a higher pulse per liter and a flow range starting at 0.05 liters per minute. That fixed the dose repeatability.
How to Read a Gicar Flow Meter Data Sheet in 60 Seconds
Start at the flow range. If your normal flow rate sits below the minimum or above the maximum, stop and choose another meter. Then check the pulse per liter. This value must give enough counts for your smallest dose. If your smallest dose is 10 mL and the meter gives 400 pulses per liter, you get 4 pulses per dose. That may be too coarse for good repeatability. Next check the output type and supply voltage. Finally check pressure, temperature, and wetted materials. Many engineers jump to the K-factor first. That is not wrong, but the flow range and repeatability determine whether the K-factor can hold in your process.
When Silver Instruments Can Help
If you have a Gicar flow meter data sheet and you need a replacement, an equivalent, or a better fit for a dosing loop, send us the full model code and your process data. Silver Automation Instruments is an industrial flow meter manufacturer and supplier with customers in Southeast Asia, Oceania, Latin America, Africa, and the Middle East. We supply Coriolis mass flow meters, electromagnetic flow meters, ultrasonic flow meters, vortex flow meters, oval gear flow meters, thermal mass flow meters, pressure transmitters, and paperless recorders. For dosing applications we often recommend an oval gear flow meter or a compact electromagnetic flow meter depending on viscosity and conductivity. Send us your flow range in liters per minute, dose volume in mL, liquid type, pipe size in DN, pressure in bar, temperature in Celsius, connector type, and conductivity in µS/cm if the liquid is not water. We will reply with a model and a wiring note.
Tel: +86-25-68650347, Whatsapp: +86-25-52155837, WeChat: +86 15365082610
FAQ: Gicar Flow Meter Data Sheet and Volumetric Dosing
What does pulses per liter mean on a Gicar flow meter?
It means the number of electrical pulses the meter sends for each liter of liquid. Use this value with the total pulse count to calculate volume. Volume in liters equals total pulses divided by pulses per liter.
How do I convert pulse count to flow rate?
Count pulses over a known time window. Convert pulses to volume by dividing by pulse per liter. Then divide the volume by the time in minutes to get liters per minute. If the meter sends 900 pulses in 30 seconds and pulses per liter is 450, the flow rate is 4 liters per minute.
What is a K-factor on a Gicar flow meter data sheet?
The K-factor is a calibration value usually expressed in pulses per liter. A higher K-factor gives more pulses per liter and can give better small dose resolution if the control system can count the frequency.
What causes missing pulses in a dosing system?
Common causes are low flow below minimum range, output frequency above the PLC input limit, wrong output type, missing pull-up resistor, electrical noise, or a damaged cable. Check these before replacing the meter.
Can you supply a replacement for a Gicar flow meter?
We can often recommend a drop-in or better meter based on the data sheet values and your process. Send us the model code, flow range, dose volume, liquid type, pipe size, pressure, temperature, and connector type. Our contact numbers are listed above.
