Vortex Meters: Saturated Steam and High-Temperature Gas Powerhouse Trackers

Quick Answer: Silver Instruments vortex meters measure saturated steam and high-temperature gas with solid repeatability. A DN50 unit tracks 50 to 800 kg/h at 10 bar, and a DN80 unit handles 150 to 2500 kg/h at 10 bar. Send your steam pressure in bar, temperature in °C, pipe size in DN, and flow range in kg/h for a model pairing.

Saturated steam is a tough application because density changes with pressure and temperature. Vortex meters are built for this job. They have no moving parts. A piezoelectric sensor sits outside the flow path. The bluff body creates a repeatable frequency signal that matches flow velocity.

We have seen many customer sites where a thermal mass meter fails on hot gas. The sensor drifts. The reading shifts. A vortex meter keeps calibration better at 180 °C or 240 °C. In practice, most steam lines are less than 20 bar. Here is the thing. You still need pressure compensation because saturation density follows pressure.

Where Vortex Meters Work Best for Saturated Steam

Silver Instruments vortex meters suit saturated steam lines from DN15 up to DN300. The bluff body creates alternating vortices. A piezoelectric sensor counts them. The signal converts to volumetric flow or mass flow when pressure compensation is active.

For saturated steam, you need density compensation. Pressure is enough because saturation links pressure to density. A built-in pressure sensor reads line pressure. The transmitter calculates mass flow in kg/h. Pressure compensation avoids a separate flow computer in many small plants.

Model Pairing for Steam Service

A common request from a chemical plant in Indonesia last year was a DN80 steam meter at 10 bar. The line ran at 184 °C. We paired a Silver Instruments VX80 vortex meter with a PT100 and an absolute pressure sensor. The flow range was 150 to 2500 kg/h. Output was 4-20 mA HART. The local display showed total flow and temperature.

For smaller lines, a DN50 meter covers 50 to 800 kg/h at 10 bar saturated steam. For DN150 lines at 8 bar, expect roughly 800 to 12000 kg/h. These ranges are starting points. Pipe size alone does not set the range. Pressure and velocity matter.

High-Temperature Gas Tracking

Hot gas applications include flue gas, hot nitrogen, compressed air after a dryer, and natural gas preheat lines. Standard vortex meters often work up to 250 °C. Silver Automation Instruments offers versions for 350 °C with a remote converter. The remote converter keeps the electronics away from radiant heat.

A customer in Vietnam runs a feed drying line. The hot air duct is DN200 at 210 °C. A vortex meter with a remote amplifier tracks the hot air flow. The previous orifice plate needed frequent cleaning. The vortex meter has no impulse lines. Maintenance dropped to visual checks.

Installation Notes From the Field

Straight pipe length matters. Most engineers skip the straight pipe requirement. A vortex meter needs 15D upstream and 5D downstream for standard accuracy. If you have an elbow before the meter, add more straight run or use a flow straightener. Vibration also affects the signal. Use a meter with vibration filtering if the pipe shakes.

For steam, install the meter on a horizontal line when possible. Keep the electronics on the side or below the pipe for high temperature. Do not let condensate sit on the sensor. Use a remote converter above 250 °C.

FAQ

What is the minimum steam pressure for a vortex meter?

Most vortex meters work in saturated steam from 1 bar and up. Below 1 bar the density is low. The signal gets weak. For stable measurement, keep velocity above 3 m/s.

Can a vortex flow meter handle superheated steam?

Yes. You need temperature and pressure inputs for mass flow. A Silver Instruments vortex meter accepts PT100 and pressure sensor inputs. The transmitter calculates mass flow from live density.

What output signals are available on Silver Instruments vortex meters?

4-20 mA HART is standard. Modbus RS485 is optional. Pulse output is also available for batching or totalizer functions. The local display shows flow, total, temperature, and pressure.

How do you size a vortex meter for saturated steam?

Send us the pipe size in DN, steam pressure in bar, temperature in °C, and flow range in kg/h. We check the velocity against the meter range. Oversizing a vortex meter is a common error. Low flow then drops below the cutoff.

What straight pipe length is required for a vortex meter?

Plan for 15D upstream and 5D downstream. D is the pipe inner diameter. If space is tight, let us know before ordering. We can select a lower flow cutoff or suggest a flow conditioner.

Contact Silver Automation Instruments for a vortex meter quote. Tel: +86-25-68650347. Whatsapp: +86-25-52155837. WeChat: +86 15365082610. Tell us your pipe size in DN, pressure in bar, temperature in °C, and flow range in kg/h.
